高精度带宽 4.5M 运算放大器 OK8551(单通道),OK8552(双通道),OK8554(四通道)
Features
Low Offset Voltage: 1uV
Input Offset Drift: 0.005μV/°C
High Gain Bandwidth Product: 4.5MHz
Rail-to-Rail Input and Output
High Gain, CMRR, PSRR:130dB
High Slew Rate: 2.7V/μs
Low Noise: 0.75uVp-p (0.01~10Hz)
Low Power Consumption: 640μA /op amp
Overload Recovery Time:1us
Low Supply Voltage: +2.7 V to +5.5 V
No External Capacitors Required
Extended Temperature: -40°C to +125°C
Applications
Temperature Sensors
Medical/Industrial Instrumentation
Pressure Sensors
Battery-Powered Instrumentation
Active Filtering
Weight Scale Sensor
Strain Gage Amplifiers
Power Converter/Inverter
Description
The OK8551,OK8552,OK8554,OK8553(dual version
&shutdown)series of CMOS operational amplifiers
use auto-zero techniques to simultaneously provide
very low offset voltage (5μV max) and near-zero drift
over time and temperature. This family of amplifiers
has ultralow noise, offset and power.
This miniature, high-precision operational amplifiers
offset high input impedance and rail-to-rail input and
rail-to-rail output swing. With high gain-bandwidth
product of 4.5MHz and slew rate of 2.7V/μs.
Single or dual supplies as low as +2.7V(±1.35V) and
up to +5.5V (±2.75V) may be used.
The OK8551/OK8552/OK8554/OK8553(dual version
with shutdown) are specified for the extended
industrial and automotive temperature range (-40°C
to 125°C). The OK8551 single amplifier is available in
8-lead MSOP8 and 8-lead SOIC packages, The
OK8552 dual amplifier is available in 8-lead SOIC and
8-lead TSSOP narrow surface mount packages, The
OK8553(dual version with shutdown) comes in Micro-
SIZE MSOP-10. The OK8554 quad is available in 14-
lead SOIC and 14-lead narrow TSSOP packages.
